The evolution of technologies such as containerization, container orchestration, and cloud-native serverless services has given us the ability to develop distributed solutions based on microservices architectures that are both more scalable and more reliable.

Microservices Architecture Sketchnote
Click to enlarge

What is microservices architecture?

Microservices architecture (often shortened to microservices) refers to an architectural style for developing applications. Microservices enable you to break down a large application into smaller independent services, with each service having its own realm of responsibility. To serve a single user request, a microservices-based application can call on many individual microservices to compose its response.

Containers are well-suited to microservices, since they let you focus on developing the services without worrying about dependencies. Modern cloud-native applications are usually built as microservices using containers.

When you use Google Cloud, you can easily deploy microservices using either the managed container service, Google Kubernetes Engine (GKE), or the fully managed serverless offering, Cloud Run. Depending on your use case, Cloud SQL and other Google Cloud products and services can be integrated to support your microservices architecture.

How are monolithic and microservices architectures different?

With a monolithic architecture, the solution is built as one large system, often with a single codebase. It is extremely difficult to change a monolith’s technology or language or framework because all components are tightly coupled and dependent on each other. As a result, even relatively small changes can require lengthy development and deployment times.

With a microservices architecture, the solution is built as a set of independent modules based on business functionality. Each module, or service, is small (“micro”),which decreases overall build and development time and makes it easy to create CI/CD pipelines. Smaller functional units also make it easy to change technology and frameworks or use different languages for different services. It’s easier to isolate faults since they are usually limited to a specific service. Services can be scaled independently, letting you scale out subsystems that require more resources, without scaling out the entire application.

Microservices use cases

Let’s consider a scenario in which you are migrating a monolithic web application or developing a new one with a microservices architecture. Microservices architectures are often event-driven with the pub/sub model, where one service publishes events and other services subscribe to the events and take action on them.

In this example scenario there are four services: Order, Packaging, Shipping, and Notification:

  • When a user places an order on the website, the Order service receives the order, does some preliminary processing, and sends the event to Google Pub/Sub.
  • The Packaging and Notification services, which are subscribed to the events from the Order service, start the packaging process for the order and send an email notification to the customer respectively.
  • The Packaging service sends an order packaging event to Pub/Sub. The Shipping service, which has subscribed to these events, processes shipping and sends an event to Pub/Sub. The Notification service consumes this event and sends another message to the customer with order shipment info.
Microservices Architecture Example Callout

Of course, there are multiple different ways of deploying a website like this. Choosing the best option will depend on your team’s specific requirements and preferences. Notice that in the example the Notification service uses Cloud Functions to run the logic for sending notifications and uses a Firestore database to look up user email addresses. The Shipping and Order services are deployed on Cloud Run while the Packaging service is deployed on GKE. They all are connecting to a Cloud SQL database.

Some other microservices use cases include:

  • Media content: Using a microservices architecture, images and video assets can be stored in a scalable object storage system and served directly to web or mobile apps.
  • Transactions and invoices: Payment processing and ordering can be separated as independent services, so payments continue to be accepted even if there is a service disruption with invoicing.
  • Data processing: A microservices platform can extend cloud support for existing modular data processing.

For a more in-depth look into migrating containers to Google Cloud check out this guide.

For more #GCPSketchnote, follow the GitHub repo. For similar cloud content follow me on Twitter @pvergadia and keep an eye out on thecloudgirl.dev

By Priyanka Vergadia, Developer Advocate, Google
